Quartz Bim

Round storage water heaters
A budget-friendly series that delivers the highest quality in reliability and durability.
Where to buy
Installation diagram ErP User Manual Certificate of Conformity
0 (800) 210 057 Free from landline phones within Ukraine
Official warranty
3-year warranty on all products
Product in stock
And ready for shipment
Delivery
Across all of Ukraine
BIO glass-ceramic inner tank
Mechanical control
Steel outer casing
Enlarged anode
Standard heating element
ErP class B
Low heat loss
  • Tank-type electric water heater with a capacity of 30, 50, 80, or 100 liters, designed for vertical installation.
  • Classic round and durable steel outer casing with powder coating.
  • Steel enamelled inner tank with BIO-glass porcelain coating, maximum working pressure of 7.5 bar.
  • High-density Super Foam insulation.
  • Mechanical temperature control via external thermostat knob.
  • Reliable stainless steel heating element with a wide 93 mm flange for easy cleaning of the tank from dirt and scale, power – 1500 W.
  • Rod thermostat with a temperature control handle.
  • Extended magnesium anode 20×200 mm.
  • Heating indicator lamp.
  • Package contents: Bim water heater, power cord with Euro plug, mounting kit (2 anchors), 7.5 bar safety valve with silicone tube, instruction manual with warranty card.
  • Tank warranty – 3 years; full warranty – 1 year.
Read more

Durability

A reliable heating element and an enlarged magnesium anode protect the tank from corrosion and keep the water in the heater consistently clean and fresh.

Ease of use

Simple mechanical PRESS & TURN control makes it easy to use the water heater and adjust the heating temperature with a single motion.

Energy-efficient

High-density polyurethane foam insulation allows hot water to stay warm longer without additional energy consumption.

Safety

The BIO-glass porcelain coating protects the inner surface of the tank from corrosion and ensures its resistance to temperature fluctuations.

Specifications

Overall dimensions (HxWxD), mm.
Mounting method
wall-mounted
Installation
vertical
Control type
mechanical
Maximum electrical power, W
1500
Inner tank material
BIO glass-ceramic
Heating element material
stainless steel
Maximum working water pressure, MPa
0.75
Maximum water heating temperature, °C
75
Connection diameter, inch
1/2
Protection class, IP
IPX4
Thermometer
No
Power-on indication
Yes
